Box Sash Windows

Introduction

Otherwise known as the double hung sliding sash, The Classic™ Box Sash Window features individual 14mm double glazed slim profile units with true bars and a traditional external putty faced finish.

In the traditional way these made-to-order timber windows use cords, weights and pulleys to counter balance the sashes. Typically Box Sash Windows would be set back in a ‘rebated reveal’ construction so that the box is mostly hidden by the external brick or stone. It can also be seen positioned close to the face of the brickwork with the box visible and dressed with an architrave.

The slim panel glazing system effectively reduces sight lines and is more in keeping with period aesthetics.

Finish

RAL Classic Range

Typically in RAL 9003 Signal White but our customers may choose from the RAL Classic swatch.

Colour matching service

On request we are able to offer a colour matching service.

Dual colour finish

We are able to offer a ‘dual finish’ where different colours are desired internally and externally or a ‘mixed finish’ where frames are specified to be contrasting to sashes.

Glazing

14mm DGU

Standard Specification

14 mm Double glass unit comprising 4 mm Tough / 6 mm Krypton / 4 mm Tough Planitherm One

Ironmongery

Chrome
Brass
Bronze
Nickel
White
Child Restrictor

Brass

Child Restrictor

Antique Brass

Child Restrictor

Polished Chrome

Child Restrictor

Satin Chrome

Child Restrictor

Satin Nickel

Child Restrictor

White

Sash Catch

Sash Catch

Hook Catch, Antique Brass

Sash Catch

Hook Catch, Brass

Sash Catch

Hook Catch, Oil Rubbed Bronze

Sash catch

Hook Catch, Polished Chrome

Sash catch

Hook Catch, Satin Chrome

Sash Catch

Hook Catch, Satin Nickel

Sash Lift

Sash Lift

Oil Rubbed Bronze

Sash Lift

Antique Brass

Sash Lift

Satin Chrome

Sash Lift

Brass

Sash Lift

Polished Chrome

Sash Lift

Satin Nickel

Sash Pulley

Sash Pulley

Antique Brass

Sash Pulley

Brass

Sash Pulley

Oil Rubbed Bronze

Sash Pulley

Polished Chrome

Sash Pulley

Satin Nickel

Sash Pulley

Satin Chrome

Technical Specifications

ThermalAs StandardBest
U-Value2.01.9
g-Value52%As Required
LT72%As Required
Weather
StandardBS6375 Part 1
AirClass 3 (EN 12207:2000)
WindClass 5 (EN 12210:2000)
WaterClass 7A (EN 12208:2000)
Operation & Strength
ClassificationPass (BS6375 Part 2)
Sustainability
FSC Chain of CustodyYes
Security
PAS 24 / Part QNo
